ELITE HUBSTANDS:

•  Designed and CNC Machined to ensure maximum precision.
•  Height (Tyre size) adjustability range 325-365mm.
•  Offset (ET) Adjustable range from 15 to -60
• Interchangeable mounting plate design
•  Load transfer bearings
• SAFETY RATING: 500 KG/Wheel

ELITE BASE PLATES:

•  Height adjustability range 50-145mm
•  Level bubble ensuring level of the base plates.
•  Hardox inserts to insure long time use

LASER ALIGNMENT KIT V2:

• Simple and fast track width measurement using width bars. No calculation is required for setup.
• Green powerful 650nm lasers.
• Custom engraved targets.
• Ability to check laser modules on the spot.
• Assembled and calibrated in house.

SCALES, CAMBER MEASURING SYSTEM:

• Integrated into the hub stand design
• Connection via bluetooth
• 0.1% Accuracy (Scales), 0.03% Accuracy (Camber)
• Hub stand position does not impact the readings of the weight

HARD TRANSPORTATION CASE:

• Stackable design
• Designed to store all of the required pit equipment
• Easy transportation
• 900X720X320mm
• Additional layers must be purchased separately

DUAL AXIS ANGLE READER

LASER LEVELING TOOL

ALL parts are designed and machined in house – Lithuania.

• Material – 6082 T6 Aluminum.
• Anodized – silver

KIT INCLUDES:

• Custom NP Pro hub stands with leveling base plates
• Billet string offset add-ons
• Digital dual axis angle reader
• Aluminium transport box
• Base leveling plate raisers
• Laser leveling tool

KEY FEATURES:

• CNC Machined from 6082 T6 Aluminium
• Machined and assembled in EU (Lithuania)
• Adjustable height ( 35 mm)
• Adjustable wheel offset ( +12 to -50)
• Interchangeable mounting plates
• Billet string offset add-ons
• Compact aluminium transportation case with foam inserts
• Custom mounting plates available on request
• Load transfer bearings

KIT POSSIBILITIES:

• TOE measurement
• Camber measurement
• Caster measurement
• Ride height measurement
•


KIT INCLUDES:

• Custom NP Pro hub stands with leveling base plates
• NP Laser alignment kit
• Digital dual axis angle reader
• Aluminium transport box
• Base leveling plate raisers
• Laser leveling tool

KIT INCLUDES:

• Custom NP Pro hub stands with leveling base plates
• NP Laser alignment kit
• Digital dual axis angle reader
• Aluminium transport box
• Base leveling plate raisers
• Laser leveling tool

KEY FEATURES:

• CNC Machined from 6082 T6 Aluminium
• Machined and assembled in EU (Lithuania)
• Adjustable height ( 35 mm)
• Adjustable wheel offset ( +12 to -50)
• Interchangeable mounting plates
• High precision laser alignment system
• Compact aluminium transportation case with foam inserts
• Custom mounting plates available on request
• Load transfer bearings

KIT POSSIBILITIES:

• TOE measurement
• Camber measurement
• Caster measurement
• Ride height measurement

 Air Jack safety stands

• CNC machined 6082-T6 Aluminum.
• Machined and assembled in EU (Lithuania).
• Lightweight construction.
• Tested on variety of cars.
• Custom made so all dimensions can be changed.
• Ertalon sleeve centering and protecting air jack from scratches.
• intended for long term use, anodized to prevent scratches.
• In stock for Krontec, AP Racing, JLS, Bilstein, Kema, Nuke.

After buying custom made, please write us required measurements.Custom production can take up to 3 weeks.

 Air jack Skates

• CNC Machined 6082 Aluminum
• Machined and Assembled in EU (Lithuania)
• Lightweight construction.
• Tested on variety of cars.
• High quality blickle wheels
• Custom made so all dimensions can be changed.
• Nylon + Molybdenum sleeve centering and protecting air jack from scratches.
• In stock for Krontec, AP Racing, JLS, Bilstein, Kema, Nuke.
